Product name: LX8983HVC2 two-wire wire testing machine product model: LX8983HVC2
LX8983HVC2 precision wire comprehensive tester
Test voltage: 200-1000vdc 100-700vac
Test points: 256P
Conduction resistance test: 0.1-50 Ω (accurate to 0.01 Ω)
Insulation resistance test: 1 m m Ω Ω - 1000
Leakage current test: 0.1-5ma
The system has automatic scanning and automatic finding function
Provide advanced short circuit, circuit breaker, dislocation conduction impedance, high voltage insulation, leakage
Current and transient short circuit test
Provide resistance, capacitance and diode component measurements
Provide single - side, standard, multi - segment and point - test function
The system provides statistics and printing function, and provides statistical analysis of defective products
Remote monitoring and RS232 communication interface
