Product name: 360 degree wire (plug lead) bending and rocking machine product model:

The machine conforms to UL817, CSA222, CCC, VDE, GB2099.1, iec884-1, SAA and other relevant standards "general safety requirements for flexible wire assembly and power supply flexible wire". Applicable to relevant manufacturers and quality inspection departments for the power line, DC wire bending test.

Used for wire, cable and all kinds of products in a certain speed, Angle, lifting weight, times and other conditions under the test of product folding resistance and performance.

Technical parameters:

LX - 817 - a model

The bending test of 6 groups of wires was carried out at the test station at the same time

Function of counting the number of test times of broken wire and power failure saving work

The total number of 0-999999 times can be set arbitrarily manually

Bending Angle 10°-360° (manually adjustable ±1°)

The test speed is adjustable from 5 to 40 times/min (the number directly shows the current test times)

Weight 50g, 100g, 200g, 300g, 500g (6 ±2g each, or as specified by the customer)

Motor precision motor AC:90W

Counter relay adopts imported omron to be stable and durable

Total power 200 w

Working power supply AC220V/50Hz/2A

Volume approx. 125*40*110cm 125*850*100cm

Weighs about 110 kg,

1 copy of operation instruction, 1 power cord, 1 set of hexagon socket
