Product name: tensile testing machine lx-8815 product model: LX8815

Lx-8815 pull-out tester

Test standard: ul-817.

Scope of application:

This machine is used to test the connection strength of the plug pair to the wire and the resistance of the wire to jerking

Strength. Fix the plug in the socket. Connect the end of the conductor to the hammer rod. Use impact

After that, the weight is hoisted to perform rotary test and e-pole

(grounding electrode) current resistance test.

Main parameters:

Number of samples :6 groups of loading anvil code :15LBX6

Twisting speed :4 times/min load current :40A/12V

Load time :3 minutes counter :6 digits

Clamp :6 sets of power :22OVAC, 50/60hz

Pull anvil code :2.5L8X6 volume product :120×50×l48Cffi

Rotary silicon code :3LB×6 weight :180kg
