I. auxiliary materials:

1. Green pyramids RKK 15P(green pyramids) 25kg

2. Yellow abrasive RKF 10K(yellow cones) 75kg

3. FC 120 compound 30kg (imported from Germany)

A. Stable, vibration-proof welded parts made of special reinforcing ribs

B. Stress-free annealed welded structure

The bushing in the c treatment tank is a hot-cast polyurethane (a resin that varies greatly in toughness and is used for strong chemical resistance)

Quality coating, adhesives and foams)

D. Thickness: 10mm

E. Slot size: deep: 180mm long: 530mmMachine Frame:

The frame of the machine

A. Groove with support, stable weld

B. The treatment groove is located on the fourth and switching part of the spiral spring

A. Combination of on and off the main switch

B. There is an on/off end button for processing speed

C. Overload protection for processing speed

D. Have a timer for the processing time

E. Possibility of connection of the measuring part

F. Triggered by the drive motor

G. Coloring: RAL 7032 pebble gray

H. Standard operating voltage: 400/230 v. 50HZ,3PH N/PE

I. Standard control voltage: 230v 50hz

J. Protection level: IP 54

K. Ambient temperature: Celsius +5 ~ +40 M1601008

V. the drive of the machine is the same as the original imported motor of the German ROSLER machine.

A. An electric motor is located under the tank to drive

B. Power: 1x0.65kw

C. Speed: 3000rpm

D. Voltage: 230/400 v. 3PH N/ pe.50h

Vi. Spare parts of consumable parts of main parts shall be equipped
