model
|
LX type weather resistance
|
LX type weather resistance
|
|
Control instrument
|
Independently developed touch screen powerful control instrument
|
|
The power supply
|
Ac 380V/50Hz, total power 28KW
|
|
Xenon lamp power
|
6KW (water-cooled all-solar spectrum long arc xenon lamp) life: 500 hours
|
|
Radiation intensity of xenon lamp
|
（300-800nm）550W/m2
|
|
Trigger power
|
6KW operating voltage 220V ac current 27±3A.
|
|
Temperature range
|
(room temperature +100C) ~ 63℃, the experimental blackboard temperature: 65℃±3℃
|
|
Humidity range
|
65±3℃
|
|
Temperature uniformity
|
≤3℃
|
|
Sample rotating basket speed
|
≤1r/min
|
|
Distance from the center of the arc to the specimen
|
476 ~ 482mm effective insolation area 6500cm2
|
|
Pour the water cycle
|
Spray for 18min, stop for 102min cycle
|
|
Studio size
|
950×950×850㎜
|
|
Hydraulic pressure
|
78～127kpa
|
|
tube
|
1only
|
|
The body material
|
SUS3042B stainless steel plate
|
|
The body shell
|
Cold plate spray plastic or SUS304 stainless steel plate
|
|
The sample frame
|
All stainless steel manufacturing, samples fixed position adjustable, standard stamping forming sample
|
|
Humidification way
|
Spray (sample spray)
|
|
convection
|
Special motor for long shaft
|
|
Conform to the standard
|
GB/T16422.31997eqvISO4892-3:1994Plastic laboratory light source exposure test method ASTMD529, iso4892-2 et al
|
|
Ventilating cooling device
|
The temperature ventilation cooling system of the test chamber is automatically controlled by a temperature controller
|
|
In the rain system
|
The rain system of the equipment consists of water pump, time relay, nozzle and so on. The spraying period can be adjusted
|
|
device
|
In order to record the working time of each test, the device is equipped with a timer on the operation panel, which can control the time of the device.
|
|
Protection device
|
In order to make the xenon arc lamp can work normally and not damage, the equipment in addition to the xenon arc lamp ignited in the circuit with cooling water chain (that is, when the cooling water is not working xenon arc lamp is not lit) and in the process of operation in case of cooling water failure work is not normal, xenon arc lamp automatically extinguished, the whole machine stopped working protection facilities
|
